16-Port 10/100Mbps PoE Switch IONNET IFS-1616 (130Watt)
– Bao gồm 16-Port PoE, công suất 130 Watt
– 16-Ports 10/100Mbps Switch with 16 ports IEEE802.3af/ 802.3at (PoE+)
– Max 30 watt per port
– Metal case, Rackmount Design 1U
Overview
IFS-1616 (130) series are 16 10/100M port Power over Ethernet which consists of 16 PSE/PoE ports.
The models compliant to PoE IEEE 802.3af, if defines new green power saving idea on PSE Port.
Features
– 16 Port PSE/ PoE function, compliant with IEEE-802.3af class3 /class 2 / class 1 and IEEE802.3at
– Supporting the power up 30Watt for each PSE/PoE port
– Providing 16 10/100Mbps switching ports
– Complying with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T, IEEE 802.3z 1000Base-SX/LX
– Comply with IEEE 802.3x Flow control; back pressure for Half-duplex and for Full-duplex mode
– All ports support Auto-MDIX function
– Being dedicated 200Mbps Full-duplex bandwidth to the each port
– Broadcast storm control and supporting store & forward operation
– Non-blocking & Non-head-of-line blocking full-wire speed forwarding
– Auto-learning networking configurations
– Built-in 4K MAC learning table, 2.75M bits buffer memory
– Support packet length up to 1536Bytes
– Filtering/ Forwarding Rate: 1000Mbps/ 1,488,000pps; 100Mbps/ 148,800pps; 10Mbps/ 14,880pps
– Status LEDs: System Power, Link/Activity, and PoE/PSE on line
– Network Transmission Media: 10Base-T Cat. 3, 4, 5 UTP/STP; 100Base-TX Cat. 5 UTP/ STP; 1000BASE-T Cat. 5E UTP/STP.
– Internal Power supply: AC input (90~260V/AC, 50~60Hz) UL Safety
– Operating Temperature: 0°C ~ 40°C
– Storing Temperature: -20°C ~ 90°C
– Humidity: 10% ~90% RH (Non-condensing)
– Dimension (L x W x H): 440 x 220 x 44mm (1U high)
– Power supply: 130Watt
– Weight: 3.5 kg
– Safety & EMI Certificates: CE & FCC
– Smart plug & play
Specifications
Standards | IEEE 802.3 10BaseT |
IEEE 802.3u 100BaseTX/100BaseFX | |
IEEE 802.3ab 1000Base-T, IEEE 802.3z 1000Base-SX/LX | |
IEEE 802.1x / IEEE 802.3af | |
Features | Number of Ports: |
16 10/100BaseT with RJ-45 Connector | |
16 PSE ports with RJ-45 Connector | |
Data Transfer Rate | Ethernet: 10Mbps/Half-Duplex, 20Mbps/Full-Duplex. Fast Ethernet: 100Mbps/Half-Duplex, 200Mbps/Full-Duplex Gigabit: 1000Mbps/Half-Duplex, 2000Mbps/Full-Duplex |
Transmission Media | 10BaseT Cat. 3, 4, 5 UTP/STP, up to 100 m |
100BaseTX Cat. 5 UTP/STP, up to 100 m | |
Led Indicators | Per Port: (TX): Link/Act, PoE. Per Unit: Power |
Power Requirement | AC input (90~260V/AC, 50~60Hz) UL Safety |
Power supply | 130 Watt |
Dimensions | 440 x 220 x 44 mm (L x W x H) |
Weight | 3.5 kg |
Operating Temperature | 0 to 40°C |
Storage Temperature | -20 to 90°C |
Humidity | 10 to 90% RH (non-condensing) |
Certifications | FCC, CE |
– Sản xuất tại Taiwan
– Bảo hành: 12 tháng
