24-port SFP Lite Layer 3 Stackable Managed Switches D-LINK DGS-3130-30S
- Layer 3 Lite Stackable Gigabit Managed Switches 24-port SFP.
- 2-port UTP 10GBase-T, 4-port 10G SFP+ (EU 2 round pin + UK 3-pin Power Cord, H/W: A1, Rack mountable).
Features
High Availability and Flexibility
- 24 SFP ports.
- 2 10GBASE-T and 4 10G SFP+ embedded uplink ports.
Reliability
- Redundant power supply (RPS) support.
- Ethernet Ring Protection Switching (ERPS) for single ring topologies.
- Embedded 6 kV surge protection on all Gigabit.
Ethernet ports
- IEEE 802.3D/802.1s Spanning Tree.
- Loopback Detection (LBD).
L3 Features
- Static Route.
- RIP.
- RIPng.
Đặc tính kỹ thuật
| Model | DGS-3130-30S |
| Ports | 24 x SFP ports |
| 2 x 10GBASE-T ports | |
| 4 x 10G SFP+ ports | |
| Optional Redundant Power Supply | DPS-500A |
| Console Port | 10/100/1000BASE-T RJ-45 port for out-of-band CLI management |
| Management Port | 10/100/1000BASE-T RJ-45 port for out-of-band IP management |
| Stacking Ports | 4 |
| Stacking Cost | 1 |
| USB Ports | 1 x USB 2.0 Type A port |
| Performance | |
| Switching Capacity | 168 Gbps |
| 64-Byte Packet Forwarding Rate | 125 Mpps |
| Packet Buffer Memory | 2 MB |
| Physical | |
| MTBF (Hours) | 487,153 hours |
| Acoustics | Max: 54 dB |
| Min: 41.1 dB | |
| Heat Dissipation | 281.16 BTU/h |
| Ventilation | 3 x Smart fans |
| Emission (EMI) | FCC Class A, CE Class A, VCCI Class A, IC, RCM, BSMI, CCC |
| Safety | CB, cUL, BSMI, CCC |
| Power Input | 100 to 240 VAC, 50 to 60 Hz |
| Max Power Consumption | 82.4 W |
| Dimensions | 440 x 250 x 44 mm |
| Weight | 3.21 kg |
- Bảo hành: 36 tháng.
