TÍNH NĂNG PHẦN CỨNG

Giao Thức và Tiêu Chuẩn

IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab,
IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p

Giao Diện

8 10/100/1000Mbps RJ45 Ports
(Auto-Negotiation/Auto MDI/MDIX)

Truyền Thông Mạng

10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m)

Fan Quantity

Fanless

Kích Thước (W x D x H)

209 x 126 x 26mm

Nguồn Điện

100~240VAC, 50/60Hz

Tiêu Thụ Điện Năng

Maximum: 6.42W (220V/50Hz)

HIỆU NĂNG

Băng Thông/Backplane

16Gbps

Bảng Địa Chỉ Mac

8k

Tốc Độ Chuyển Tiếp Gói Tin

11.9Mpps

Khung Jumbo

9216 Bytes

TÍNH NĂNG PHẦN MỀM

Chất Lượng Dịch Vụ

Support 802.1p CoS/DSCP priority
Support 4 priority queues
Queue scheduling: SP, WRR, SP+WRR
Port/Flow- based Rate Limiting
Voice VLAN

Tính Năng L2

IGMP Snooping V1/V2/V3
802.3ad LACP (Up to 6 aggregation groups,
containing 4 ports per group)
Spanning Tree STP/RSTP/MSTP
BPDU Filtering/Guard
TC/Root Protect
Loop back detection
802.3x Flow Control

VLAN

Supports up to 512 VLANs simultaneously (out of 4K VLAN IDs)

Danh Sách Kiểm Soát Truy Cập

L2 ~ L4 package filtering based on source and destination MAC address, IP address, TCP/UDP ports, 802.1p,DSCP, protocol and VLAN ID
Time Range Based

Bảo Mật

SSH v1/v2
SSL v2/v3/TLSv1
Port Security
Broadcast/Multicast/Unknown unicast Storm Control

Quản Lý

Web-based GUI and CLI management, SNMP v1/v2c/v3, compatible with public MIBs and TP-LINK private MIBs, RMON (1, 2, 3, 9 groups), CPU Monitoring, Port Mirroring, Time Setting: SNTP, Firmware Upgrade: TFTP & Web
System Diagnose: VCT
SYSLOG & Public MIBS

OTHERS

Certification

CE, FCC, RoHS

Package Contents

TL-SG2008
Power Adapter
Quick Installation Guide
Resource CD
Rubber Feet

System Requirements

Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC® OS, NetWare®, UNIX® or Linux.

Environment

Operating Temperature: 0°C~40°C (32°F~104°F)
Storage Temperature: -40°C~70°C (-40°F~158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
