Bộ khuếch đại công suất 60W TOA VP-1061
The VP-1061 is a 60W 1 channel power amplifier designed exclusively for rack mount use. The compact design is capable of delivering high output power and is highly durable, operating on both AC and DC power.
Specifications
| Model | VP-1061 |
| Power Source | AC: 230 VAC, 50/60 Hz DC: 24 VDC |
| Power Consumption | AC: 170 W (at rated output), 100 W (EN60065), 14 W (no signal) DC: 4.5 A (at rated output), 0.1 A (no-signal) |
| Rated Output | 60W |
| Input | 2 program inputs (parallel), 0 dB, 20 kΩ, balanced 2 priority inputs (parallel), 0 dB, 20 kΩ, balanced |
| Impedance | 167Ω (100 V) |
| S/N Ratio | 80 dB or more |
| Total Harmonic Distortion | 1% or less (at rated output f = 1 kHz) |
| Frequency Response | 80 – 16,000 Hz, ±3 dB (at 1/3 rated output) |
| Ventilation | Fan cooling |
| Operating Temperature | 0ºC to +40ºC |
| Operating Humidity | 90% RH or less (no condensation) |
| Finish | Panel: Aluminum, black, alumite |
| Dimensions | 210 x 88.4 x 338.7 mm |
| Weight | 6.9kg |
- Sản xuất tại Trung Quốc.
- Bảo hành: 12 tháng.
