Video Compression

H.264, MJPEG

Image Sensor Resolution

Megapixel Progressive Scan CMOS, 1280H x 720V

Image Sensor Sensitivity

Day/Night Mode (exceptional low noise level, low light sensitivity). Shutter: 1/10000 - 1/30 second

Focal Length

2.8mm

Aperature

F1.8

IR Cut Filter

Yes, Mechanical

Day & Night Mode

IR LED with full software control

Minimum Illumination

0 Lux

Pan/ Tilt

176º/ 70º

Sensitivity

3300mV / (lux-sec)

Supported Maximum Video Resolution and Frame Rate

1280 x 720 (30fps)

Video Bit Rate

32 Kbps ~ 8Mbps, Multi-rate for Preview and Recording

Audio Input

Built-in Microphone; 3.5mm Line-In (1.5KΩ)

Audio Output

Built-in Speaker; 3.5mm Line-Out (600Ω, 0.707 Vrms)

Alarm Input

Yes, Vin < 15V, PINs

Alarm Output

Yes, 125VAC/0.5A, 30VDC/2A, Normal Open, PINs

Integrated Microphone

Yes

Integrated Speaker

Yes

SIP/VoIP Support

Yes

Privacy Mask Support

Yes, 4 Zones

Smart IR Support

Yes (Optimal White Balance and Exposures)

Time-Lapse Recording

Yes

Micro SDHC Card

Yes (up to 32GB)

Snapshots

Triggered upon Events, Send via email and/or FTP

Audio Compression

G.711u/A (PCMU, PCMA)

Embedded Analytics

Motion Detection (up to 16 target areas)

Pre-/post-alarm Recording

Yes

Power over Ethernet (PoE)

IEEE 802.3af Class 2; 10M/100M Auto-sensing, 2KV Lightning Surge Protection

Network Protocol

TCP/UDP/IP, RTP/RTCP, RTSP, DHCP, DDNS, HTTP, HTTPS, SMTP, FTP, NTP

Power Adapter

Output: 12VDC/0.5A; Input: 100-240VAC, 50-60Hz

Casing

Plastic Case for Indoor Only

Dimensions

138 x 93mm

Weight

0.4kg
