Specification:
| Transmit Frequency | 125KHz / 13.56MHz |
| Read Range | 5~10cm / 2~6cm |
| Card Compatibility | EM or ISO14443A/B/ 15693 / Mifare |
| Keypad | 12 keys |
| Communication | RS485 / Wiegand(26/32/34/35/37/42/50/66 bits) |
| ID | 0,001 ~ 9,999 |
| Anti-Tamper Facility | Built-in(IR) |
| Buad Rate | 19,200 bps (4,800~230,400 bps) |
| Beep Tone | Built-in Buzzer |
| LED Indicator | 3 LED |
| LCD Display | 128x64 Dots (16x4 Char) LCD with backlight |
| Language | Multi-Language Support Unicode |
| Anti-Tamper Facility | Built-in |
| Encryption | 256 bit AES(fingerprint data protection) |
| Operating temperature | -10˚C ~ +60˚C |
| Input Voltage | 8V ~ 20V DC / 0.5W ~ 2W |
| Dimensions(mm) | 89.4 x 124 x 12 mm |
