Processor

Dual-core Intel® processor

Memory

4GB RAM

HDD Capacity

4 x 3.5-inch SATA 6Gb/s, SATA 3Gb/s hard drive

HDD Tray

4 x Hot-swappable and lockable tray

LAN Port

2 x Gigabit RJ-45 Ethernet port

LED Indicators

Status, LAN, USB, HDD1-4

USB

2 x USB 3.0 port (Back: 2)

5 x USB 2.0 port (Front: 1; Back: 4)

Support pen drive, USB mouse, USB keyboard, USB sound card, and USB UPS etc.

Buttons

Power button, One-touch-auto-video-backup button, Reset button

LCD Panel

Mono-LCD display with backlight
Enter button, Select button for configuration

Alarm Buzzer

System warning

Audio

Audio In/Out (reserved)

Form Factor

Tower

Dimensions

185 (H) x 180 (W) x 235 (D) mm

7.28 (H) x7.09 (W) x 9.25 (D) inch

Weight

Net weight: 4.6 kg (10.14 lbs)

Gross weight: 5.9 kg (13.00 lbs)

Operation Environment

Temperature 0~40˚C

Humidity 0~95% R.H.

Power Supply

Input: 100-240V AC, 50/60Hz, Output: 250W

Power Consumption

In Operation: 62.7W
(with 6 x 2TB HDD installed)

Secure Design

K-Lock security slot for theft prevention

Video Output

1x HDMI

Suggested video output resolution: 1920 x 1080 (Full HD)

Fan

1 x quiet cooling fan (92 mm, 12V DC)

Certification

CE, FCC, VCCI, BSMI
