Din-Rail Power Supply 40W/24V PLANET PWR-40-24
- Universal AC input / full range
- Protection: short circuit, overload and over voltage
- Cooling by free air convection
- For installation on DIN rail TS-35/7.5 or 15
- NEC class 2 / LPS compliant
- LED indicator for power on
- DC OK relay contact
- No load power consumption: <0.75W
- 100% full load burn-in test
Specifications
| Dimensions (W x D x H) | 40 x 100 x 90 mm |
| Weight (kg) | 0.3kg |
| Input Voltage | 100-240V AC, 50/60Hz, 1.1A |
| Power Output | 40 watts, 24V, 1.7A |
| Temperature | Operating: -20~70 degrees C |
| Storage: -40~85 degrees C | |
| Humidity | Operating: 20 ~ 90% |
| Storage: 10 ~ 95% (non-condensing) | |
| Installation | DIN Rail TS-35/7.5 or 15 |
| Safety & Function | UL508, TUV EN60950-1 approved, NEC class 2 / LPS compliant |
- Bảo hành: 12 tháng.
