- Ethernet: 10 / 100Base - T / Tx1, Automatic MSI / MDI-xport
- Communication Port: RS-232 / 485 / 422
- RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND, 1200bps ~ 230.4 kbps
- RS-485: 2 DATA +/-
- RS-422: 4 R+ / R- / T+ / T-
- CPU: 16 Bits, 100MHz
- Memory: 256K Flash & 2M SDRAM
- Watch Dog: System halt prevention
- I/O Port: 3 DI / 3 DO
- LED Indicator: 10: Power / RXD / TXD / ACT / IN1 / IN2 / IN3 / OUT1 / OUT2 / OUT3
- Power Requirement: DC 9V ~ 24V
- Power Consumption: 500mA (9V)
- EMI / EMC Certification: FCC B, CE B
- System Requirement:
- (1) Operation Temperature: 0°C ~ 55°C
- (2) Storage Temperature: -20°C ~ 75°C
- (3) Operation Humidity: 5% ~ 85% RH
- Surge Protection: Serial port 15 KV ESD
- Magnetic Protected: Ethernet port 1.5 KV
- Connector Type: DB9 (Male) / RJ-45 / 2 RS-485 / 4 RS-422
- Reset Button: Yes
- Dimension: 106.5 (Include ear loop) x 115 x 28 mm
- Weight: 340 g
