FEATURES HIGHLIGHTS

• 400 sets of function key.
• Anti-pass back / Anti duress.
• Basic Time attendance (First IN / Last OUT).
• Color screen with touch keypad.
• LOGs data real time PUSH.
• Indoor and outdoor use (IP65 certificated).
• Standalone, Web-Based Management and network capability.
• Support DHCP for easy setup.

GENERAL DATA

• Software Application: SoMac / Browser
• Verification Mode: Fingervein / Card / PIN / Match on card
• Proximity: EM / Mifare / HID
• Fingervein Module: HITACHI H1EAX (ISO/IEC 19795-1)
• Fingervein Template Capacity: 12,000
• 1:1 Verification Time: 1 sec
• 1:1,000 Identification Time: 1.5 sec
• FAR (False Acceptance Rate): 0.01%
• FRR (False Rejection Rate): 0.0000067%
• User Capacity: 10,000
• Function Keys: 400 SET
• Time Sets / Time Zones / Group: 255 / 120 / 255 SET
• Holiday Dates: 100 SET
• Access&Event Logs / System Logs: 65536 / 2688
• Inputs: 3 Inputs, (1) Exit button
• Relay Outputs: 1 output for Lock (COM / NO / NC)
• Web Base Management: Yes
• Support real time log: Yes
• PUSH methodology: Yes
• Wiegand Inputs: 26/34 bits Wiegand reader
• IP Mode: Static IP / AUTO IP (DHCP Client)
• LED Indicators: 3 Colours (RGB)
• Speaker Indication: Optional
• Buzzer: Single Tone
• TFT Color LCD : 2.8"
• Capacitive Touch Keys: 4 x 4
• Anti-Tampering Switch: Yes
