FEATURES HIGHLIGHTS

• Android mobile NFC
• 400 sets of function key.
• Anti-pass back / Anti duress.
• Basic Time & Attendance (First IN / Last OUT).
• Color screen with touch keypad.
• LOGs data real time PUSH.
• Indoor and outdoor use (IP65 certificated).
• Standalone, WEB-Based Management and network capability.
• Support AUTO Get IP (DHCP) for easy setup.

GENERAL DATA

• Software Application: SoMac / Browser / APP
• Verification Mode: Fingerprint / Card / PIN
• Proximity: EM / Mifare / HID
• Fingerprint Template Capacity: 9,590
• Fingerprint Sensor Type: Optical
• Fingerprint Sensor Resolution: 500 dpi
• 1:1 Verification Time: < 600 msec
• 1:1,000 Identification Time: < 760 msec
• User Capacity: 20,000
• Function Keys: 400 SET
• Time Sets / Time Zones / Group: 255 / 120 / 255 SET
• Holiday Dates: 100 SET
• Access & Event Logs / System Logs: 65536 / 1536
• Inputs: 3 Inputs, (1) Exit button (2) Door Sensor (3) Fire Alarm
• Relay Outputs: 1 output for Lock (COM/NO/NC)
• Web Base Management: Yes
• Support real time log PUSH methodology: Yes
• Wiegand Inputs: 26/34 bits Wiegand reader
• Wiegand Outputs: 26/34 bits Wiegand reader
• IP Mode: Static IP / AUTO IP (DHCP Client)
• LED Indicators: Blue / Green / Red LED
• Speaker: Indication: Optional
• Buzzer: Single Tone
• TFT Color LCD : 2.8"
• Capacitive Touch Keys: 4 x 4
• Anti-Tampering Switch: Yes

COMMUNICATION DATA

• TCP / IP: 10 / 100 Base-T
• Wiegand: 26 / 34 bits

ELECTRICAL DATA & CONDITIONS

• Power Consumption: 500 mA ± 5%
• Operation Voltage: 9 ~ 24VDC / 1A
• Output Relay: 30VDC, 1A
• Operation Temperature: 0°C ~ 65°C
• Operation Humidity: 5% ~ 80% RH

PHYSICAL DATA

• Dimension: 160.2 x 140.2 x 46.7mm
• Weight: 0.6 kg
• Installation: Indoor / Outdoor (IP65 weatherproof)
