FEATURES HIGHLIGHTS

• Standalone Access Controller
• Sub-Controller, Dummy Reader modes.
• Fingerprint / Card / Fingerprint + Card verification mode.
• Optical fingerprint sensor module.
• Proprietary software (SoMac) support.
• Built-in http server.

PRODUCT SPECIFICATION

• Software Application: SoMac
• Verification Mode: Fingerprint / Card (Not support Keypad)
• Template Capacity: 9,590
• Sensor Type: Optical
• Resolution: 500dpi
• Sensing Area: 16 x 19mm
• Template Size: 256 ~ 384 Bytes
• Image Size: 272 x 320 (pixel)
• 1:1 Verification time: < 600msec
• 1:1,000 Identification time: < 760msec
• Card Capacity: 20,000
• Communications: TCP/IP, Wiegand/RS485
• DIO Support: DI: 3 / DO: 1
• Inbuilt Relays (Max. power loading): Door Lock (40VAC / 40VDC, 2A)
• System Log: 1,536 entries
• Entry Log: 51,968 entries
• Time Zone / Time Set / Group: 255 / 120 / 255 Sets
• Holiday: Yes
• Remote Control / Event Handle: Yes / Yes
• Fast Registry: Yes
• Function Key (Auto): 400 (set BF-670W as Controller)
• Anti-Pass Back: Yes
• Power Consumption: 500mA ± 5%
• Power Requirement: 9 ~ 24VDC / 1A
• Operation Temperature: 0°C ~ 65°C
• Operation Humidity: 5% ~ 80% RH
• Dimension / Weight: 160 x 56.9 x 40.1mm / 150g

REMARKS

• Web Server, supported by Chiyu Technology's SOMAC Central management software. Access Control and Time & Attendance. Features like anti-passback, user accession, group accession, door setup by verification methods
• All products with 2 years warranty.
