Camera IP Speed Dome hồng ngoại 2.0 Megapixel HIKVISION DS-2SE4C225MWG-E(12F0)
Camera cố định ColorVu
- Cảm biến hình ảnh: 1/2.8” Progressive Scan CMOS
- Ống kính: 2.8 mm
- Độ phân giải: 1920 × 1080@30fps
- Hỗ trợ đèn ánh sáng trắng lên đến 30m
- Độ nhạy sáng: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light
Camera PTZ powered-by-DarkFighter
- Cảm biến hình ảnh: 1/2.8” Progressive Scan CMOS
- Độ phân giải: 1920 × 1080@30fps
- Chuẩn nén: H.265+/H.265
- Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR
- Ống kính: 4.8 to 120 mm
- Zoom quang: 25x
- 120 dB WDR, HLC, BLC, 3D DNR, Digital defog, EIS
- Chức năng chụp ảnh khuôn mặt Face capture
- Tầm quan sát hồng ngoại: 100 m
- Nguồn điện: 24 VAC & Hi-PoE
- Alarm: 1 in / 1 out
- Audio: 1 in / 1 out
Thông số kỹ thuật
| Model | DS-2SE4C225MWG-E(12F0) |
| Camera | |
| Image Sensor | [Bullet channel]: 1/2.8' Progressive Scan CMOS [PTZ channel]: 1/2.8' progressive scan CMOS |
| Min. Illumination | [Bullet channel]: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light; [PTZ channel]: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Shutter Speed | 1/1 s to 1/30,000 s |
| Slow Shutter | Yes |
| Focus | semi-auto, manual, auto |
| Day&Night | ICR |
| Zoom | [PTZ channel] 25 × optical, 16 × digital |
| Day/Night Switch | day, night, auto, scheduled-switch |
| White Balance | auto, ATW, sodium lamp, fluorescent lamp, indoor, outdoor, MWB, Locked WB |
| Max. Resolution | [Bullet channel] 1920 × 1080, [PTZ channel] 1920 × 1080 |
| Lens | |
| Lens | [Bullet channel]: 2.8 mm; [PTZ channel]: 4.8 to 120 mm, 25 × optical |
| FOV | [Bullet channel]: Horizontal field of view: 106.1°, Vertical field of view: 56.8°, Diagonal field of view: 126.5° [PTZ channel]: Horizontal field of view: 54.8° to 2.8° (wide-tele), Vertical field of view: 31.4° to 1.5° (wide-tele), Diagonal field of view: 62.2° to 3.2° (wide-tele) |
| Aperture | [Bullet channel]: F1.0; [PTZ channel]: F1.6 |
| Zoom Speed | [PTZ channel]: approx. 3.6 s |
| Illuminator | |
| Supplement Light Type | [PTZ channel]: IR; [Bullet channel]: White Light |
| Supplement Light Range | [PTZ channel]: up to 100 m; [Bullet channel]: up to 30 m |
| Smart Supplement Light | Yes |
| PTZ | |
| Movement Range (Pan) | 0° to 360° |
| Movement Range (Tilt) | -5° to 90° |
| Pan Speed | configurable from 0.1° to 80°/s; preset speed: 80°/s |
| Tilt speed | configurable from 0.1° to 80°/s, preset speed 80°/s |
| Proportional Zoom | Yes |
| Presets | 300 |
| Preset Freezing | Yes |
| Patrol Scan | 8 patrols, up to 32 presets for each patrol |
| Pattern Scan | 4 pattern scans |
| Park Action | preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan |
| 3D Positioning | Yes |
| PTZ Status Display | Yes |
| Preset Freezing | Yes |
| Scheduled Task | preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust |
| Exception Detection | IP address conflict, HDD full, illegal login, HDD error, network disconnected, Abnormal Reboot |
| Power-off Memory | Yes |
| Video | |
| Video Compression | H.265,H.264,MJPEG |
| SVC | Yes |
| Region of Interest (ROI) | 8 fixed regions for each stream |
| Audio | |
| Audio Sampling Rate | 8 kHz, 16 kHz, 32 kHz, 48 kHz |
| Environment Noise Filtering | Yes |
| Audio Compression | G.711, G.722.1, G.726, MP2L2, PCM, AAC-LC |
| Smart Features | |
| Smart Record | ANR, Dual-VCA |
| Image | |
| SNR | ≥ 52 dB |
| Image Setting | sharpness, saturation, brightness, contrast |
| Image Enhancement | BLC, HLC, 3D DNR |
| Image Parameters Switch | Yes |
| Defog | Digital Defog |
| Wide Dynamic Range (WDR) | 120 dB |
| Image Stabilization | EIS |
| Privacy Mask | [Bullet channel] 8 programmable polygon privacy masks, [PTZ channel] 24 programmable polygon privacy masks; mask color or mosaic configurable |
| Regional Focus | Yes |
| Regional Exposure | Yes |
| Network | |
| Protocols | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour, WebSocket, WebSockets |
| User/Host | Up to 32 users. 3 user levels: administrator, operator and user |
| API | Open Network Video Interface (Version 19.12, Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
| Simultaneous Live View | Up to 20 channels |
| Interface | |
| Alarm | 1 input, 1 output |
| Audio | 1 audio input, 2.0 to 2.4Vp-p, 1k Ohm±10% 1 audio output, line level, impedance: 600 Ω |
| On-board Storage | Built-in memory card slot, support Micro SD/Micro SDHC/Micro SDXC, up to 256 GB |
| Hardware Reset | Yes |
| Ethernet Interface | RJ45, self-adaptive 10M/100M Ethernet por |
| Event | |
| Basic Event | Motion detection, video tampering alarm, exception, alarm input and output |
| Smart Event | audio exception detection, region entrance detection, region exiting detection, intrusion detection, Line crossing detection |
| Linkage | [Bullet channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, and trigger recording [PTZ channel] Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, and PTZ actions (such as preset, patrol scan, pattern scan) |
| Deep Learning Function | |
| Face Capture | [Bullet channel] no,[PTZ channel] yes |
| General | |
| General Function | mirror, password protection, watermark, IP address filte |
| Power | 12VDC, PoE+ |
| Power Consumption and Current | Max. 24 W, including max. 2.6 W for heater and max. 11 W for supplement light |
| Startup and Operating Conditions | -30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing) |
| Reset | Yes |
| Demist | Demist by heating the glass |
| Material | ADC12 |
| Dimensions | Ø 166 mm × 375 mm |
| Weight | Approx. 2.4 kg |
- Bảo hành: 24 tháng.
