IP-Remote Microphone TOA IP-100RM
- IR-100RM is a network remote microphone. It can be used for general broadcast and emergency broadcast.
- The microphone can received messages from server or other devices. It can also distribute these messages to selected zone or all zones.
- Status LED next to every button allows operator to acquire status of each zone and other operation status at one glimpse.
- Can support Max. 1000 zoning
Specifications
| Model | IP-100RM |
| Power Source | DC24V |
| Current Consumption | Below 200mA (single IP-100RM), below 500mA (connected with 9 pieces of RM-110) |
| Audio Input | 1V rms (Max: 2V rms), 10kΩ electronically balanced gooseneck microphone |
| Audio Output | 1V rms, unbalance 600Ω or unbalanced, 11.25mW, 32Ω |
| Frequency Response LINE IN LINE OUT (Network broadcast) SPEAKER OUT(Network broadcast) | (Sampling rate: 22k), 20Hz -10kHz (MP3 / sampling rate: 44k), 40Hz - 20kHz (MP3/ sampling rate: 44k), 20Hz - 20kHz |
| Control Input | Optic coupler shortage input, open voltage DC 5V, maximum shortage current ≤5mA |
| Built-in Monitor Speaker | Maximum output 1W |
| Volume control | Microphone volume control, monitor speaker volume control |
| Number of Function Keys | 15 on single equipment. Expandable to 105 with 9 sets of RM-210 connected. |
| Maximum Zoning Support | 1000 |
| Network I/F | 10 BASE-T/ 100 BASE-TX Auto Negotiation |
| Network Protocol | UDP, ARP, ICMP, HTTP, IGMP |
| Operation Temperature | 0°C to +40°C |
| Operation Humidity | Less than 90% RH (no condensation) |
| Finish | ABS resin, bluish gray |
| Dimensions (W x H x D) | 190 x 76.5 x 215 mm (not included the gooseneck microphone) |
| Weight | 0.8kg |
- Sản xuất tại Trung Quốc.
- Bảo hành: 12 tháng.
