Business Access Point Wireless N300 with PoE LINKSYS LAPN300
- Wireless Access Point chuẩn N, hoạt động với tần số 2.4 GHz.
- Cổng kết nối LAN Gigabit hỗ trợ cấp nguồn PoE.
- Hỗ trợ 08 SSID, 08 VLAN, mỗi SSID hỗ trợ tối đa kết nối 64 Users.
- Anten 2x2 internal high power với kỹ thuật MIMO gia tăng vùng phủ sóng và loại bỏ điểm chết.
- Hỗ trợ tính năng Repeater, Bridge.
- Sẵn sàng hỗ trợ thoại IP và video streaming chất lượng cao.
- Thiết kế để bàn hoặc treo trần nhà gọn đẹp
- Employs Wi-Fi technology (802.11n) to provide a fast, powerful wireless network at a transfer rate of up to 300 Mbps.
- Integrated Power over Ethernet
- Single Band (2.4GHz) capability and speeds up to 300 Mbps
- Industrial-strength Wi-Fi Protected Access (WPA, WPA2) security and data encryption
- IPv6 Support
- High Power PA for better Wi-Fi coverage
UP TO N300 MBPS
Provides high-speed connectivity for notebooks, smartphones, tablets, and other Wi-Fi enabled devices
GIGABIT ETHERNET PORT
Wireless clients can enjoy faster speeds by maximizing wireless-to-wired performance. Gigabit Ethernet is 10x faster than Fast Ethernet.
HIGH POWER WIRELESS COVERAGE
High power offers better, wider wireless coverage for you and your business, strengthening your network connection in hard-to-reach areas.
3-IN-1 ACCESS POINT, WDS & WORKGROUP BRIDGE
Extends wired and wireless range with three modes: traditional access point, wireless distribution system (WDS), or wireless bridge.
EASY TO USE WITH POE
Integrated with 802.3af Power over Ethernet (PoE) capability to eliminate external adapters and facilitate optimal placement.
ADVANCED NETWORK SECURITY
Protect your network with advanced security features including Rogue AP detection, SSID to VLAN mapping, and 802.1X Supplicant.
Technical specifications
- Network Standards:
o IEEE 802.11n
o IEEE 802.11g
o IEEE 802.11b
- Radio Frequency Bands:
2.4 GHz
- Ports:
1 Gigabit Ethernet Port
- PoE:
o 802.3af
o 802.3at
- LEDs:
One system LED
- MIMO:
2x2
- Antenna Type:
Internal
- Antenna Gain:
1.8 dBi
- RF Transmit Power:
o 802.11b @ 11 Mbps: 21 dBm
o 802.11g @ 54 Mbps: 20 dBm
o 802.11n @ HT20/HT40 MCS7/15: 19 dBm
- Radio Frequency Channels:
2.412 to 2.462 GHz; 11 channels
- Receiver Sensitivity:
o 802.11b @ 11 Mbps: -85 dBm
o 802.11g @ 54 Mbps: -70 dBm
o 802.11n @ HT20 MCS7/15: -65 dBm
o 802.11n @ HT40 MCS7/15: -62 dBm
- Maximum Power Consumption:
12.5W
- Dimensions (LxWxH):
243.08 x 236.98 x 43.69 mm (9.57 x 9.33 x 1.72 in)
- Weight:
489.88 g (1.08 lb)
- Operating Temperature:
0° to 40°C (32° to 104°F)
- Storage Temperature:
-20° to 70°C (-4° to 158°F)
- Operating Humidity:
10% to 85% (non-condensing)
- Storage Humidity:
10% to 90% (non-condensing)
- Mounting:
o Wall
o Ceiling
o Desktop
- Number of VLANs Supported:
9, 1 management VLAN plus 8 VLANs for SSID
- Security Lock:
Kensington Lock Slot
- Access Control:
MAC-Based
- Management Interface:
o HTTP
o HTTPS
o SNMP
- Regulatory Compliance:
o FCC, CE, IC
o Class B, Wireless
- Event Notification:
Local Log, Remote Syslog, and Email Alert
- Network Diagnostics:
Log, Ping, Packet Capture
- Warranty and Support:
Limited Lifetime
- 802.1X Supplicant:
Yes
- External Power Amplifier:
Yes
- Isolation of Wireless Clients in the Same SSID:
Yes
- Reset Button:
Yes
- Rogue AP Detection:
Yes
- Scheduler:
Yes
- SSID to VLAN Mapping:
Yes
- Wireless Security:
o WEP
o WPA
o 802.1X RADIUS
- WMM:
Yes
- Workgroup Bridge:
Yes
