Mains power supply

Voltage

230 VAC ±10%, 50/60 Hz (reduced power at lower mains or battery voltage)

Inrush current

10A

Power consumption

400 VA

Performance

Frequency response

50 Hz to 20 kHz (+1/‑3 dB @ ‑10 dB ref. rated output)

Distortion

<1% @ rated output power, 1KHz

Bass Control

Max -12/+12 dB (frequency is setting dependent)

Treble Control

Max -12/+12 dB (frequency is setting dependent)

RJ45 input

1 x

Mic/Line input

4 x

Input 1 (Push-to-talk contact with ducking functionality)

5-pin Euro style, balanced, phantom

3-pin XLR, balanced, phantom

Input 2-4 (VOX with ducking functionality on input 2)

3-pin XLR, balanced, phantom

Sensitivity

1 mV (mic); 1 V (line)

Impedance

>1KΩ (mic); >5KΩ (line)

Dynamic range

93 dB

S/N (flat at max volume)

>63 dB (mic); >70 dB (line)

S/N (flat at min volume/ muted

>75 dB

CMRR (mic)

>40 dB (50 Hz to 20 kHz)

Headroom

>17 dB

Speech filter

-3 dB @ 315 Hz, high-pass, 6 dB/oct

Phantom power supply

16 V via 1.2 KΩ (mic)

Music input

3x

Connector

Cinch, stereo converted to mono

Sensitivity

300 mV

Impedance

22KΩ

S/N (flat at max volume)

>70 dB

S/N (flat at min volume/ muted)

>75 dB

Headroom

>25 dB

Emergency / telephone

1 x

Connector

7-pin Euro style pluggable screw connector

Sensitivity Tel

1 V maximum

Sensitivity 100V

100 V maximum

Impedance

>10KΩ

S/N (flat at max volume)

>65 dB

VOX

Threshold 50 mV; attack time 150 ms; release time 2 s

Master/music output

1 x

Connector

3-pin XLR, balanced

Nominal level

1 V

Impedance

<100Ω

Loudspeaker output 8Ω

Connector

Euro style pluggable screw terminal, floating

Rated

31V (120 W)

Acoustic noise level of fan

< 33dB SPL @ 1m

Mounting

Stand-alone, 19 inch rack

Color

Charcoal

Dimensions

100 x 430 x 270 mm

Weight

Approx. 10.5 kg
