Mains power supply

Voltage

230/115 VAC, ±10%, 50/60 Hz

Inrush current

7 A at 230 VAC / 14A at 115 VAC

Max power consumption

500 VA

Performance

Output current

10:00 SA

Frequency response

50 Hz to 10 kHz (+1/-3 dB at -10 dB ref. rated output)

Distortion

<1% at rated output power, 1KHz

Bass control

-8/+8 dB at 100 Hz

Treble control

-8/+8 dB at 10 kHz

Mic / line input

2 x

Connectors

3-pin XLR, balanced mic/line level (switchable)

Sensitivity

1 mV / 1 V (mic/line)

Impedance

>1 KΩ

Dynamic Range

100 dB

S/N (flat at max volume)

75 dB

Headroom

25 dB

Phantom power supply

16 V (switchable)

VOX functionality

Input 1 (switchable) mutes input 2

VOX sensitivity

-10 dB ref nominal input

Priority input

Connectors

Screw

Sensitivity

100 V, transformer balanced

Impedance

>100 KΩ

S/N (flat at max volume)

63 dB

Headroom

25 dB

Pilot tone detection

-20 dB, ref 100 V (10 V)

Pilot tone threshold

-26 dB, ref 100 V (5 V)

Master input

1 x

Connector

1/4 inch TS jack

Line output

Connector

3-pin XLR, balanced

Nominal level

1 V

Impedance

200Ω

Loop output

Connector

Screw

Slave output

(for master input of other PLN-1LA10)

Impedance

<100Ω

Connector

 1/4 inchTS jack 0° to 90º

Fault Relay

Connector

Screw

Contacts

100 V, 2 A (voltage free, SPDT)

Mechanical

Mounting

Stand-alone, 19 inch rack

Color

Charcoal

Dimensions

94 x 430 x 320 mm

Weight

11.6 kg
