FEATURES HIGHLIGHTS

• Compatible with CSS-R11 for Single or multi doors control structure.
• Built-in Watch-dog (Watch Dog).
• Support door sensor detection, short or open.
• Support Wiegand input, exit button, door sensor, WG reader contacts
• CSS-A11 supports POE for easy installation
• RS485 communication control relay for providing the high security level. In the emergency mode, when controller is disconnected, exit button still could have function.

PRODUCT SPECIFICATION

• Model Name : CSS-A11 (POE Power Supply)
• PoE Standard : IEEE802.3af(15.4W)
• PoE Received Pin : Support 1/2+、3/6- line pair (Mode A), 4/5+、7/8- line pair (Mode B)
• PoE Distance : Max 100M
• PoE Max. Output : DC 12V/1.2A
• Protocol Standard : IEEE 802.3i；IEEE 802.3u, IEEE 802.3x Flow Control, IEEE 802.3af DTE Power via MDI, IEEE 802.3at DTE Power via MDI
• Interface Protection : IEC61000-4-2(ESD)±15KV(air), ±8KV(contanc) 8/20us 24A(12A)
• Wiegand Range : Max 100M
• Relay Power Requirement : Max DC 30V 3A (Doesn't support AC POWER)
• Dimension : 105.05 x 71.75 x 28.3 mm
• Weight : 135g
