Camera IP 2.0 Megapixel Vivotek IP9165-HP

Vivotek IP9165-HP

  • MS 000009751
  • VIVOTEK
Giá : 25,860,000 vnđ (Đã bao gồm VAT)

Camera IP 2.0 Megapixel Vivotek IP9165-HP

Camera IP 2.0 Megapixel Vivotek IP9165-HP

- Cảm biến hình ảnh: 1/2 inch Progressive CMOS.

- Độ phân giải camera ip: 2.0 Megapixel.

- Chuẩn nén hình ảnh: H.265/H.264/MJPEG.

- Ống kính: 3.6 ~ 17 mm.

- Công nghệ chống ngược sáng WDR Pro (140dB).

- Chức năng ổn định hình ảnh kỹ thuật số DIS.

Đặc tính kỹ thuật

Camera Features
Image Sensor1/2 inch Progressive CMOS
Maximum Resolution1920×1080
Lens TypeVari-focal, Remote Back Focus
Focal Lengthf = 3.6 ~ 17 mm
ApertureF1.5 ~ F2.8
Iris typeP-iris (DC-iris reserved)
Field of View28° ~ 100° (Horizontal)
16° ~ 55° (Vertical)
32° ~ 119° (Diagonal)
Shutter Time1/5 sec. to 1/32,000 sec.
WDR TechnologyWDR Pro II
Day/NightYes
Removable IR-cut FilterYes
Minimum Illumination0.01 Lux @ F1.5 (Color)
0.005 Lux @ F1.5 (B/W)
Pan/tilt/zoom FunctionalitiesePTZ:48x digital zoom (4x on IE plug-in, 12x built in)
On-board StorageSlot type: MicroSD/SDHC/SDXC card slot (Max. SD card capacity:128GB)
Seamless Recording
Video
CompressionH.265, H.264, MJPEG
Maximum Frame Rate60 fps @ 1920×1080
Maximum Streams4 simultaneous streams
S/N Ratio66.2 dB
Dynamic Range140 dB
Video StreamingAdjustable resolution, quality and constant, bit rate control; Smart Stream III
Image SettingsAdjustable image size, quality and bit rate; Time stamp, text overlay, flip & mirror; Configurable brightness, contrast, saturation, sharpness, white balance, exposure control, gain, backlight compensation, AE speed, privacy masks; Scheduled profile settings, HLC, defog, 3DNR, DIS, video rotation, lens profile
Audio
Audio CapabilityTwo-way audio
CompressionG.711, G.726
InterfaceExternal microphone input
External line output
Network
UsersLive viewing for up to 10 clients
ProtocolsIPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP, IGMP, CIFS/SMB, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS, QoS, SNMP, 802.1X, UDP, ICMP, ARP, TLS
Interface10 Base-T/100 Base-TX/1000 Base-T Ethernet (RJ-45)
ONVIFSupported, specification available at www.onvif.org
Intelligent Video
Video Motion DetectionFive-window video motion detection
Alarm and Event
Alarm TriggersMotion detection, manual trigger, digital input, periodical trigger, system boot, recording notification, camera tampering detection, audio detection, advanced motion detection, MicroSD card life expectancy
Alarm EventsEvent notification using digital output, HTTP, SMTP, FTP, NAS server and MicroSD card
File upload via HTTP, SMTP, FTP, NAS server and MicroSD card
General
ConnectorsRJ-45 cable connector for Network/PoE connection *1
Audio input *1
Audio output *1
DC 12V/AC 24V power in *1
Digital input *2
Digital output *2
RS485 *1
BNC *1
LED IndicatorSystem power and status indicator
Power InputIEEE 802.3af PoE Class 0
DC 12V
AC 24V
Power ConsumptionDC 12V: Max. 9 W
AC 24V: Max. 18 W
PoE: Max. 9.06 W
Dimensions227 x 70 x 61 mm (w/ lens)
Weight800g (w/ lens)

- Bảo hành: 36 tháng.
