Wired Glass Break Detector HIKVISION DS-PDBG8-EG2
- High quality Omni-directional microphone sensor.
- Up to 8m/120° detection coverage.
- Selectable EOL resistors (Alarm Resistance: 1K, 2K2, 4K7, 5K6, 6K8).
- 9-16 VDC wide voltage adaptation with polarity reverse connection protection.
Đặc tính kỹ thuật
| Detection Performance | |
| Detection Method | Acoustic Sensor |
| Detection Range | 8m |
| Detection Angle | 120° |
| Glass Break Sensitivity | Potentiometer Adjustment |
| Glass Type | Float, Plate, Tampered, Wired, Laminated Leaded, Double Glazing |
| Glass Thickness | 2.4 mm to 6.4 mm |
| Glass Size | 0.3 m x 0.3 m to 3 m x 3 m |
| Feature | |
| Digital Processing | Support |
| Tamper Protection | Front |
| Interface | |
| Alarm Output | Normally Closed |
| LED Indicator | Red (High Frequency Trigger), Green (Low Frequency Trigger), Blue (Alarm) |
| Transmission | |
| Transmission Method | Wired |
| Electrical Characteristics | |
| Power Supply | 9-16 VDC |
| Typical Voltage | 12 V |
| Power Consumption | 25 mA |
| General | |
| Operation Temperature | -10 °C to 55 °C (14 °F to 131 °F) |
| Storage Temperature | -20 °C to 60 °C (-4 °F to 140 °F) |
| Operation Humidity | 10% to 90% |
| Dimension (W x H x D) | 38.8 mm × 107 mm × 22.5 mm |
| Weight | 49.5 g |
| Mounting Method | Wall, Ceiling |
| Application Scenario | Indoor |
- Bảo hành: 24 tháng.
