Device Type

Wireless Access Point

Ruggedized Design

Indoor

Expansion / Connectivity

Interfaces

1 x 1000Base-T - RJ-45

1 x management - RJ-45

Networking

Form Factor

External

Features

DFS support, MIMO technology, Wi-Fi Multimedia (WMM) support, rogue access point detection, ClientLink 2.0 technology, CleanAir Express technology, Cisco BandSelect technology, Cisco VideoStream technology

Connectivity Technology

Wireless

Data Link Protocol

IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n

Compliant Standards

IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11d, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11h, IEEE 802.11n, IEEE 802.3at

Data Transfer Rate

300 Mbps

Status Indicators

Error, status

Encryption Algorithm

AES, TLS, PEAP, TTLS, TKIP, WPA, WPA2

Authentication Method

MS-CHAP v.2, EAP-FAST

Frequency Band

2.4 GHz, 5 GHz

Miscellaneous

Compliant Standards

VCCI, ICES-003, EN 300.328, EN 301.489.1, EN 301.489.17, FCC Part 15.247, OET 65 C, RSS-210, RSS-102, UL 2043, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15.107, FCC Part 15.109, AS/NZS 4268, EN 301.893, FCC Part 15.407, EN 60601-1-2, ARIB STD-T66, ARIB STD-T71, ARIB STD-T33, CAN/CSA C22.2 No. 60950-1, EMI

Power

Power Over Ethernet (PoE) Supported

PoE

Environmental Parameters

Min Operating Temperature

-30 °C

Max Operating Temperature

70 °C

Humidity Range Operating

10 - 90% (non-condensing)

Processor / Memory / Storage

RAM

256 MB

Flash Memory

32 MB

Aerial

Antenna

Internal integrated

Gain Level

4 dBi

Dimensions

22.1 x 22.1 x 4.7cm

Weight

1.04 kg
