Wireless Accesst Point Meraki CISCO MR24
- Highest performance, highest capacity for high density campus and enterprise.
- Support 900 Mbit/sec max rate, 3x3 MIMO with 3 streams, beamforming, 1×Gigabit Ethernet port, 3-stream, 3x3 MIMO, Priority Voice, Power Save (802.11e/WMM) Very high performance multi-radio mesh.
- 3x3 802.11n MIMO with three spatial streams.
- Up to 900 Mbps combined throughput.
- Enhanced transmit power and receive sensitivity.
- Self-healing, zero-configuration mesh.
- Integrated enterprise security and guest access.
- Application-aware traffic shaping.
- Self-configuring, plug-and-play deployment.
- Sleek, low profile design blends into office environments.
- Optimized for voice and video.
- Real-time WIPS with Air Marshal.
Specification
| Radios | One 802.11b/g/n and one 802.11a/n radio Dual concurrent operation in 2.4 and 5 GHz bands Max throughput 900 Mbit/s |
| 802.11n Capabilities | 3 x 3 multiple input, multiple output (MIMO) with three spatial streams Maximal ratio combining (MRC) Beamforming 20 and 40 MHz channels Packet aggregation Cyclic shift diversity (CSD) support |
| Power | Power over Ethernet: 37 - 57 V (802.3af compatible) 12 V DC Power consumption: 12.5 W max Power over Ethernet injector and DC adapter sold separately |
| Mounting | All standard mounting hardware included Desktop and wall mount Ceiling tile rail (9/16, 15/16 or 1 ½” flush or recessed rails), assorted cable junction boxes |
| Physical Security | Security screw included Kensington lock hard point Padlock hard point (Master Lock 120T or equivalent) Anti-tamper cable bay Concealed mount plate |
| Environment | Operating temperature: 32 °F to 104 °F (0 °C to 40 °C) Humidity: 5 to 95% non-condensing |
| Physical Dimensions | 8.6” x 6.2” x 1.4” (218 mm x 157 mm x 36 mm) not including deskmount feet or mount plate Weight: 22 oz (0.62 kg) |
| Antenna | Integrated omni-directional antennas Gain: 3 dBi @ 2.4 GHz, 5 dBi @ 5 GHz |
| Interfaces | 1x 100/1000Base-T Ethernet (RJ45) with 48V DC 802.3af PoE 1x DC power connector (5 mm x 2.1 mm, center positive) |
| Security | Integrated policy firewall (Identity Policy Manager) Mobile device policies Air Marshal: Real-time WIPS (wireless intrusion prevention system) with alarms Rogue AP containment Guest isolation Teleworker VPN with IPsec PCI compliance reporting WEP, WPA, WPA2-PSK, WPA2-Enterprise with 802.1X TKIP and AES encryption VLAN tagging (802.1q) |
| Quality of Service | Wireless Quality of Service (WMM/802.11e) Advanced Power Save (U-APSD) DSCP (802.1p) Layer 7 application traffic shaping and firewall |
| Mobility | PMK and OKC credential support for fast Layer 2 roaming L3 roaming |
| LED Indicators | 4 signal strength 1 Ethernet connectivity 1 power/booting/firmware upgrade status |
| Regulatory | FCC (US), IC (Canada), CE (Europe), C-Tick (Australia/New Zealand) Anatel (Brazil), Cofetel (Mexico), TK (Turkey) RoHS |
| Mean Time Between Failure (MTBF) | 450,000 hours |
| Certifications | Wi-Fi Alliance |
- Bảo hành: 12 tháng.
