Cáp mạng Alantek Cat5e FTP 4-pair
Part Number: 301-10F08E-03GY
- Alantek CAT5E Twisted Pair Cable is designed to support high-bandwidth application up to 1 Gigabit Ethernet. The cable is composed of 24AWG Bare Solid Copper conductors insulated with High Density Polyethylene (HDPE) insulation (1.03mm). For the Shielded cable, the insulated conductors are twisted into pair and completed with an Outer Jacket an additional layer of Aluminium Laminated Foil covers the 4 twisted pairs of insulated conductor.
- Application: Horizontal wiring suitable for application up to 1 Gigabit Ethernet.
- Standards: TIA/EIA 568B, ISO/IEC 11801, UL 444.
- Color: Grey.
- Packaging: 305m/reel.
Specifications
- Conductor
o Material: Solid bare copper.
o Size: 24AWG x 4 Pairs.
o Diameter: 1/0.50 +/- 0.02mm.
- Conductor Insulation
o Material: HDPE
o Min. Ave. Thickness: 0.21 mm
o Min. Thickness at any point: 0.20 mm
o Deameter: 0.92 +/- 0.02 mm
- Jacket
o Material: PVC.
o Min. Ave. Thickness: 0.52 +/- 0.02 mm.
o Min. Thickness at any point: 0.50 mm.
o Diameter: 5.0 +/- 0.2mm.
- Max Tensile Load (Installation): 100N.
- Sản xuất tại Trung Quốc.
