Cáp mạng Alantek Cat6 FTP 4-pair

Cáp mạng Alantek Cat6 FTP 4-pair

  • MS 000001805
  • ALANTEK
Giá : 3,555,000 vnđ (Đã bao gồm VAT) Giảm giá 8 %
3,900,000 vnđ

Cáp mạng Alantek Cat6 FTP 4-pair

Cáp mạng Alantek Cat6 FTP 4-pair

Part Number: 301-60FULG-03GY hoặc 301-60F8LG-03GY

- Alantek Cat6 Twisted Pair Cable is designed to support high-bandwidth application up to 10Gigabit Ethernet. The cable is composed of 23 AWG bare solid copper conductors insulated with High Density Polyethylene (HDPE) insulation. For the unshielded cable, the 4 twisted pairs are separated by a flexible PE separator and the cable is completed with an Outer Jacket. For the shielded cable, an additional layer of Aluminium Foil covers the 4 twisted pairs.

- Application: Horizontal wiring, suitable for application up to 10 Gigabit Ethernet.

- Standards: TIA/EIA 568B, ISO/IEC 11801, UL 444.

- Color: Grey.

- Packaging: 305m/reel.

Specifications

- Conductor

o Material: Solid bare copper.

o Size: 23AWG x 4 Pairs.

o Diameter: 1/0.56 ± 0.01mm.

- Conductor Insulation

o Material: HDPE

o Min. Ave. Thickness: 0.23 mm

o Min. Thickness at any point: 0.22 mm

o Deameter: 1.03 ± 0.01 mm

- Jacket

o Material: PVC

o Min. Ave. Thickness: 0.52 ± 0.02 mm

o Min. Thickness at any point: 0.50 mm

o Diameter: 6.4 ± 0.2mm

- Max Tensile Load (Installation): 100N.

- Sản xuất tại Trung Quốc.
