Chuyển đổi Quang-Điện Media Converter Unmanaged Fiber Switch BTON BT-922GS-20
-2 Ethernet Port 10/100Mbps and 2 x 100Base-F(X) port, Single Mode, 20 km, SC.
-Chuyển đổi quang điện Media Converter 10/100 Base-Tx đến 1000 Base-LX, Dual Fiber Single mode.
-Tích hợp 2 cổng Ethernet (RJ45) 10/100Mps và 2 cổng 100Base-F(X).
-Khoảng cách truyền: 20 km.
-Bước sóng quang hoạt động: 1310nm.
-Ngõ giao tiếp quang: Connector SC.
-Ngõ giao tiếp mạng: RJ45.
-Tương thích các chuẩn: IEEE802.3u, 10/100 Base-TX, 100Base-FX.
-Các đèn LED chỉ thị nguồn, FX LINK/ ACT, 100, TP LINK/ ACT, FDX/ COL.
Features
-Flow control for full duplex and half duplex.
-Supports up to 10k byte JUMBO frame.
-Supports Fiber Port Trunking, Increasing Fiber Channel Bandwidth and Supply Fiber Channel Redundancy.
-Supports Ports Based VLANS and TAG Based VLANS.
-In conformity to safety code of FCC and CE MARK.
-Connector: Multi-UTP RJ-45 connector, one or two fiber connector
-Operation mode: full duplex mode or half duplex mode
-Power supply parameter: 5VDC 1A/2A
-Environmental temperature: 0-50°C.
-Relative humidity: 5%-90%
-UTP cable: Cat5 UTP cable
-Transfer fiber: multimode (50/125, 62.5/125 or 100/140um); single mode(8.3/125,8.7/125, 9/125 or 10/125um).
Specifications
| Model | BT-922GS-20 |
| Rate | 10/100Mbps and 100Base-F(X) |
| Protocol | Supported IEEE802.3 |
| Fiber type | Dual fiber |
| Optic mode | Single Mode |
| Ethernet interface | RJ-45 |
| Optic interface | SC/FC/ST |
| Optic wavelength | 850nm, 1310nm, 1550nm, 1310/1550nm, 1490/1550nm |
| BER | < 1/1000000000 |
| Power | 2.5W |
| Power supply | 220VAC/0.5A, 48VDC/0.5A, 5VDC/1A, 2A |
| Working temperature | 0~50ºC |
-Sản xuất tại Trung Quốc.
-Bảo hành: 12 tháng.
