Công tắc cảm ứng ánh sáng THEBEN LUNA 112 top3 EL
- Part Number: 1120230.
- Công nghệ kỹ thuật số, 2 kênh điều khiển.
- Lập trình bằng ứng dụng kết nối qua Bluetooth.
- Ngưỡng hoạt động: 0~99.000 lx.
- Cảm biến rời, gắn chìm (EL), IP20.
- Thời gian trễ (mở): 0~59 phút.
- Tải: 16A at 250 VAC, cos φ = 1, 10A at 250 VAC, cos φ = 0.6, 230V, 50-60Hz.
- Gắn Din (2 modules).
- Mở rộng tối đa 4 cảm biến.
- Tải tối đa cho đèn sợ đốt 2600W.
- Khoảng cách tới cảm biến 100 mét.
Đặc tính kỹ thuật
| Model | LUNA 112 top3 EL |
| Operating voltage | 100 – 230 VAC |
| Frequency | 50 – 60 Hz |
| Number of channels | 2 |
| Stand-by consumption | ~0.8 W |
| Setting range brightness | 1 – 99000 lx |
| Preset brightness value | 15 lx |
| Switch-on delay | 0 – 59 min |
| Switch-off delay | 0 – 59 min |
| Type of contact | Two-way changeover contact |
| Width | 2 modules |
| Installation type | DIN rail |
| Type of connection | DuoFix spring terminals |
| Display | LCD-Display |
| Keyboards | 4 touch buttons |
| Switching capacity | 16 A at 250 V AC, cos φ = 1, 10 A at 250 V AC, cos φ = 0.6 |
| Incandescent/halogen lamp load | 2600 W |
| Halogen lamp load | 2600 W |
| Fluorescent lamp load (conventional) not corrected | 2600 VA |
| Fluorescent lamp load (conventional) parallel-corrected | 130 µF |
| LED lamp < 2 W | 50 W |
| LED lamp 2-8 W | 600 W |
| LED lamp > 8 W | 600 W |
| Lichtsensor | Flush-mounted light sensor |
| Housing and insulation material | High-temperature resistant, self-extinguishing thermoplastic |
| Ambient temperature | -25°C ... 55°C |
| Type of protection | IP 20 |
| Protection class | II, Sensor III |
| Max. cable length to sensor | 100 m |
- Hãng sản xuất THEBEN của Đức.
- Bảo hành: 12 tháng.
