FEATURES HIGHLIGHTS
- IP54 Outdoor weather proof reader controller.
- Multiple card types support (EM / Mifare standard).
- PoE (Power over Ethernet) function support (option).
- Inbuilt HTT web server for management.
- Proprietary software provide for advance management.
PRODUCT SPECIFICATION
- Verification Mode: Card / Password
- Software Application: SoMac
- Card Capacity: 20,000 (50,000 extendable)
- Communications: TCP/IP, Wiegand/RS485
- DIO Support: DI: 3 / DO: 1
- Inbuilt Relays (Max. power loading): Door Lock / Ring (120VAC, 0.5A / 30VDC, 1A)
- Power Over Ethernet: Yes (Option) (Conjunction box required)
- Option Accessories: Conjunction box (Wiring / PoE)
- System Log: 1,536 entries
- Entry Log: 65,535 entries
- Time Set / Time Zone / Group: 255 / 120 / 255 Sets
- Holiday: Yes
- Remote Control / Event Handle: Yes / Yes
- Fast Registry: Yes
- Ant-Pass Back / Anti Duress: Yes / Yes
- Power Consumption: 400mA ± 5%
- Power Requirement: 9 ~ 24VDC / 1A
- Operation Temperature: 0°C ~ 65°C
- Operation Humidity: 5% ~ 80% RH
- Dimension / Weight: 120 x 80 x 28mm / 150g
