WAN Protocol

Ethernet

PPPoE, PPTP, DHCP client, static IP, L2TP, IPv6

Multi WAN

Outbound policy based load balance

Allow your local network to access Internet using multiple Internet connections with high-level of Internet connectivity availability.

4 dedicated Ethernet WAN ports (10/100/1000Mbps) and 1 active fiber (SFP) slot.

WAN fail-over or load-balanced connectivity.

Redundancy.

By WAN interfaces traffic volume.

By destination IP address range.

By fixed VPN connection.

Flexible pooling rule setting.

Auto-detect line status.

Service/IP based preference rules or auto-weight.

Bandwidth on demand

Service/IP based preference rules or auto-weight

VPN

Prevent Replay Attack

Protocols

PPTP, IPSec, L2TP, L2TP over IPSec.

Up to 500 connections simultaneously

LAN to LAN, remote access (teleworker-to-LAN), dial-in or dial-out.

VPN trunking

VPN load-balancing and VPN backup.

VPN throughput

760Mbps.

NAT-traversal (NAT-T)

VPN over routes without VPN pass-through.

PKI certificate

Digital signature (X.509).

IKE authentication

Pre-shared key; IKE.

Authentication

Hardware-based MD5, SHA-1.

RADIUS client

Authentication for PPTP remote dial-in.

DHCP over IPSec

Because DrayTek add a virtual NIC on the PC, thus, while connecting to the server via IPSec tunnel, PC will obtain an IP address from the remote side through DHCP protocol, which is quite similar with PPTP.

GRE over IPSec

Creating a virtual point-to-point link to various brands of routers at remote sites over an IP internetwork.

Content filter

IM/P2P blocking

Java applet, cookies, active X, compressed, executable, multimedia file blocking.

Web content filter

Web content filter

Dynamic URL filtering database.

Time schedule control

Set rule according to your specific office hours.

Firewall

Stateful Packet Inspection (SPI)

Outgoing/ Incoming traffic inspection based on connection information.

Multi-NAT

You have been allocated multiple public IP address by your ISP. You hence can have a one-to-one relationship between a public IP address and an internal/private IP address. This means that you have the protection of NAT (see earlier) but the PC can be addressed directly from the outside world by its aliased public IP address, but still by only opening specific ports to it (for example TCP port 80 for an http/web server).

DoS/DDoS prevention

Act of preventing customers, users, clients or other computers from accessing data on a computer.

System management

Web-based user interface (HTTP)

Integrated web server for the configuration of routers via Internet browsers with HTTP.

Quick start wizard

Quick start wizard

Let administrator adjust time zone and promptly set up the Internet (PPPoE, PPTP, Static IP, DHCP).

User management

Dial-in access management (PPTP/L2TP and mOTP)

CLI(Command Line Interface, Telnet/SSH)

Remotely administer computers via the telnet.

DHCP client/relay/server

Provides an easy-to configure function for your local IP network.

Tag-based VLAN (802.1Q)

By means of using a VLAN ID, a tag-based VLAN can identify VLAN group membership. The VLAN ID provides the information required to process the traffic across a network.Furthermore, the VLAN ID associates traffic with a specific VLAN group.

Firmware upgrade via TFTP/HTTP

Using the TFTP server and the firmware upgrade utility software, you may easily upgrade to the latest firmware whenever enhanced features are added.

Certificate management

Advance encrypted method

A pair of public/priviate key for encryption/decryption.

Comprehensive Certificate Authentication

Trusted CA / Local Certificate / CA server.

Routing functions

Router

IP and NetBIOS/IP-multi-protocol router.

Advanced routing and forwarding

Complete independent management and configuration of IP networks in the device, i.e. individual settings for DHCP, DNS, firewall, VLAN, routing, QoS etc.

DNS

DNS cache/proxy.

DHCP

DHCP client/relay/server.

NTP

NTP client, automatic adjustment for daylight-saving time.

Dynamic routing

It is with routing protocol of RIP v2. Learning and propagating routes.

High availability

CARP

Common address redundancy protocol.

Enhanced security with encrypted packet.

Hardware

LAN

2 x 10/100/1000M Base-TX LAN switch, RJ-45

1 x active fiber (SFP) slot

WAN

4 x 10/100/1000M Base-TX WAN switch, RJ-45

1 x active fiber (SFP) slot

Console

1 x console, RJ-45

Reset

1 x factory reset button

USB

2 x USB host 2.0
