Dipole Antenna Cisco AIR-ANT2506
- Cisco Aironet Omni-Directional Mast Mount Antenna.
- AIR-ANT2506= designed for WLAN applications in the 2.4–2.5 GHz frequency range, the antenna has a nominal gain of 5.2 dBi and is typically mounted indoors or outdoors on a mast.
- The antenna is compatible with Cisco Aironet radio products utilizing a reverse polarity TNC (RP-TNC) connector.
Specification
| Antenna type | Dipole |
| Operating frequency range | 2.4–2.84 GHz |
| Environment | Indoor/outdoor |
| Nominal input impedance | 50 Ohms |
| VSWR | Less than 2:1, 1.5:1 nominal |
| Gain | 5.2 dBi |
| Polarization | Linear, vertical |
| E-Plane (3dB bandwidth) | 36 degrees |
| H-Plane (3dB bandwidth) | Omni-directional |
| Cable length and type | 3 ft. (0.91 m) RG-58 |
| Dimensions (H x W) | 11.5 in x 1.125 in. (29.2 cm x 2.8 cm) |
| Mounting | Mast, 2 in (5.08 cm) maximum |
| Operating temperature range | -22–158° F (-30–70° C) |
