5-Port Web Managed PoE Gigabit Switch ZyXEL GS1200-5HPV2
- The Zyxel GS1200-5HPV2 is equipped with 5 Gigabit ports includes 4 PoE ports compliance with IEEE 802.3at and automatically detect and supply power up to 60W total PoE budget.
- The Zyxel GS1200-5HPV2 is more than just a typical PoE switch. It comes with an easy-to-use web configuration to prioritize, limit and/or protect network traffics. It has been designed specifically for customers who require simple control functions for office network management.
Standard Compliance
- IEEE 802.3u 100BASE-TX Ethernet
- IEEE 802.3ab 1000BASE-T Ethernet
- IEEE 802.3az EEE support
- IEEE 802.3x flow control
- IEEE 802.3z 1000BASE-X
- IEEE 802.1p CoS
- IEEE 802.3af PoE
- IEEE 802.3at PoE Plus (30W per port)
- Auto MDI/MDI-X
- IEEE 802.1Q VLAN tagging
Features
- Web-based management
- System password
- VLAN (Port supported): 5 ports
- Port-based QoS
- 802.1p CoS
- Broadcast storm control
- Loop detection/prevention
- DHCP client
- Link aggregation: one LAG (Port 3&4)
- Port mirroring
- Weighted Round Robin (WRR) priority QoS
- IGMP snooping v1/v2/and v3 compatible
- Supported multicast groups: 128
- Firmware update
Specifications
| Model | GS1200-5HPV2 |
| Port Density | |
| Total port count | 5 |
| 1000BASE-T | 1 |
| 1000BASE-T PoE | 4 |
| Performance | |
| Switching capacity | 10 Gbps |
| Packet buffer | 128 KB |
| MAC address | 2K |
| Jumbo frame | 9 KB |
| LED | |
| Power | Yes |
| Per port | Yes |
| PoE power status | Yes (Max) |
| Power | |
| Input voltage | 55 V/ 1.3 A |
| Power supply | External |
| Maximum power consumption (watt) | 72 |
| PoE power budget (watt) | 60 |
| Physical Specifications | |
| Dimensions (WxDxH) | 193 x 84 x 26 mm |
| Weight | 392 g |
| Environmental Specifications | |
| Operating Temperature | 0°C to 40°C/32°F to 104°F |
| Operating Humidity | 10% to 90% (non-condensing) |
| Storage Temperature | -40°C to 70°C/-40°F to 158°F |
| Storage Humidity | 10% to 90% (non-condensing) |
- Xuất xứ tại Trung Quốc.
- Bảo hành: 24 tháng.
