Đầu báo rung không dây HIKVISION DS-PDMCK-EG2-WB
- Khoảng cách kết nối đến trung tâm báo động: 1000m (trong không gian trống).
- Nhận biết các rung động.
- Có thể mở rộng thêm 2 cùng có dây.
- Có chỉ báo cường đó tín hiệu.
- Có thể cấu hình từ xa qua APP.
- Chiều cao lắp đặt: 2.4m đến 3.6m.
- Loại pin: 1 x CR123A (kèm sẵn trong thiết bị, thay thế dễ dàng).
- Tuổi thọ pin: khoảng 3 năm.
Features
- Magnetic contact combined with shock and tilt detection.
- 2 wired inputs extension.
- Fully remote configurable through App.
- Multiple enrollment methods and easy installation design.
- Frequency hopping against jamming for reliable transmission.
Đặc tính kỹ thuật
| Model | DS-PDMCK-EG2-WB |
| Detection Performance | |
| Detection Method | Opening Contact;Shock Sensor |
| Detection Gap | 43mm Max |
| Sensitivity | Shock Detection: High, Normal, Low Tilt Detection: Up to 25° |
| Feature | |
| Digital Processing | Support |
| Tamper Protection | Front; Rear |
| Environment Temperature Indicator | Support |
| Signal Strength Indicator | Support |
| Interface | |
| Alarm Input | Normally Closed;Normally Open;Impulse Count |
| Power Switch | Power Up Enrolling |
| LED Indicator | Green(MC),Orange(tilt),Red(shock),Blue(alarm) |
| Transmission | |
| Transmission Technology | Tri-X Wireless |
| Transmission Method | Two-Way RF Wireless |
| Transmission Frequency | 433MHz |
| Transmission Security | AES-128 Encryption |
| Transmission Range(Free Space) | 1km |
| Frequency Hopping | Support |
| Enrolling Method | Power up;Remote ID;QR Code |
| Electrical | |
| Standard Battery Life | 3 years in work status (being triggered 20 times per day) |
| Power Supply | Battery Powered |
| Battery Type | CR123A x 1 |
| Typical Voltage | 3V |
| Application Scenario | Indoor |
| General | |
| Operation Temperature | -10 °C to 55 °C (14 °F to 131 °F) |
| Storage Temperature | -20 °C to 60 °C (-4 °F to 140 °F) |
| Operation Humidity | 10% to 90% |
| Dimension | 22.5mm × 103mm × 23.2mm 22.5mm × 103mm × 23.2mm |
| Weight | 60g |
- Bảo hành: 12 tháng.
