General

Ethernet Interface

2 x 10/100/1000 Mbps WAN Ports

4 x 10/100/1000 Mbps LAN Ports

USB 2.0 Ports

1

Console Port

RJ45

Performance

Firewall Throughput

950 Mbps

VPN Throughput

70 Mpps

Concurrent Sessions

30000

New Sessions (per second)

300

Firewall Policies

300

Internet Connection Type

Static/ Dynamic IP

PPPoE/ L2TP/ PPTP

Multiple PPPoE

Firewall System

Static Route

Dynamic DNS

Inter-VLAN Route

NAT, PAT

Web Content Filtering: Static URL, Keywords

Intrusion Prevention System (IPS): Signature Package Included in Firmware

Networking

DHCP Server/ Client

DHCP Relay

IEEE802.1q VLAN

VLAN (Port-Based)

IP Multicast: IGMP Proxy

IPv6

3G Redundancy

Virtual Private Network (VPN)

VPN Tunnels: 85

IPSec Tunnels: 35

SSL VPN Tunnels: 10

PPTP/L2TP Clients: 25

GRE: 15

Encryption Methods: DES, 3DES, AES, Twofish, Blowfish, CAST-128, NULL

SSL Encryption Methods: RC4-128, 3DES, AES

IPSec/PPTP/L2TP Server

IPSec NAT Traversal

Dead Peer Detection

IP Encapsulating Security Payload (ESP)

IP Authentication Header (AH)

VPN Tunnel Keep Alive

Hub and Spoke

Bandwidth Management

Maximum Bandwidth Control

Priority Bandwidth Control: Port-based QoS, 3 Classes

System Management

Web-based User Interface: HTTP, HTTPS

Command Line

SNMP v1, v2c, v3

Power Supply

External Power Supply Unit

Input: 100-240VAC, 50/60Hz

EMI/EMC

FCC Class B, CE Class B, C-Tick, IC

Safety

cUL, LVD (EN60950-1)

MTBF

260,000 hours

Max. Power Consumption

15.6 W

Dimensions

180 x 280 x 44 mm
