Reyee AX6000 High-density Outdoor Directional Access Point RUIJIE RG-RAP6260(H)-D
- Ultra-fast 5.95 Gbit/s outdoor Wi-Fi 6, best-in-class Wi-Fi performance.
- Easily adding extra outdoor Wi-Fi with Reyee mesh.
- Long-distance deployment with optical ports.
- IP68 rating, adapting to harsh environments.
- Internet access with 2.5 Gbit/s uplink.
Thông số kỹ thuật
| Basic Feature | |
| Wi-Fi Standards | Wi-Fi 6 (IEEE 802.11ax) Wi-Fi 5 (IEEE 802.11ac Wave 2) Wi-Fi 4 (IEEE 802.11n) IEEE 802.11a IEEE 802.11b/g |
| MIMO | 2.4GHz, 4x4, MU-MIMO 5GHz, 4x4, MU-MIMO |
| Max. Wi-Fi Speed | 2.4GHz: 1148Mbps 5GHz: 4804Mbps |
| Antenna | 8 |
| Antenna Type | Built-In directional |
| Antenna Gain | 2.4GHz: 10dBi 5 GHz: 9dBi |
| Transmit Power | Frequency bands using and the max EIRP: Note: Country specific restrictions apply European Union & United Kingdom 2400-2483.5 MHz, EIRP≤ 20 dBm 5470-5725 MHz, EIRP≤ 30 dBm United States: 2400-2483.5 MHz, max output power≤30dBm & EIRP ≤ 36 dBm 5150-5250 MHz, max output power≤30dBm & EIRP ≤ 36 dBm 5250-5350 MHz, max output power<24dBm & EIRP ≤ 30 dBm 5470-5725 MHz, max output power<24dBm & EIRP ≤ 30 dBm 5725-5825 MHz, max output power≤30dBm & EIRP ≤ 36 dBm Myanmar : 2400-2483.5 MHz, EIRP ≤ 23 dBm 5725-5825 MHz, EIRP ≤ 30 dBm Thailand: 2.4 GHz to 2.4835 GHz: 20 dBm 5.470 GHz to 5.725 GHz: 30 dBm 5.725 GHz to 5.825 GHz: 30 dBm Indonesia: 2400-2483.5MHz, EIRP ≤ 36 dBm 5725-5825MHz, EIRP ≤ 36 dBm Egypt: 2400-2483.5 MHz, EIRP ≤ 20 dBm 5150-5350 MHz, EIRP ≤ 23 dBm |
| Fixed Ports | 1 x 100/1000/2500 Base-T port 1 x 1GBase-X SFP port 1 x DC port 1 × Reset button |
| Max. Clients | 512 |
| Recommended Clients | 130 |
| Max. SSIDs | 8 |
| Recommended Wi-Fi Coverage Radius | 2.4GHz: 50 meters 5GHz: 150 meters The Wi-Fi coverage is related to the installation environment of the access point. |
| Max. Wi-Fi Coverage Radius | 1 km |
| Operation Frequency Bands | 802.11b/g/n/ax: 2.400 GHz to 2.4835 GHz 802.11a/n/ac/ax: 5.150 GHz to 5.350 GHz, 5.470 GHz to 5.725 GHz, 5.725 GHz to 5.850 GHz country-specific restrictions apply |
| Software Feature | |
| Power Adjustment | Yes |
| Frequency Bandwidth | 2.4 GHz: Auto/20/40 MHz 5 GHz: Auto/20/40/80/160 MHz |
| Roaming | Layer 2 roaming Layer 3 roaming 802.11k/v/r |
| OFDMA | Yes |
| Beamforming | Yes |
| WMM | Yes |
| Radar Signal Detection and Frequency Hopping(DFS) | Yes |
| WLAN Security | |
| Wi-Fi Password | 16 Digits |
| Security Mode | WPA-PSK, WPA2-PSK, WPA/WPA2-PSK |
| Blacklist and Whitelist | Yes |
| Wi-Fi Optimization | Yes |
| STA Limit | Yes |
| Removing Low-RSSI STAs | Yes |
| Adjusting Sending Rate of Beacon and Probe Response | Yes |
| Syslog Recording Why Users Lose Connection | Yes |
| Auto Channel and Power Adjustment on Cloud | Yes |
| RSSI Threshold for STA Access | Yes |
| Load Balancing | Yes |
| Networks | |
| Network Access Mode | PPPoE Client DHCP Client Static IP |
| VLAN | Yes |
| DHCP Server | Yes |
| System | |
| Cloud Management | Yes |
| APP Management | Yes |
| APP Upgrade | Yes |
| APP Restart | Yes |
| Scheduled Restart | Yes |
| Default Access/Password | 10.44.77.254 The factory status password: admin |
| Local Upgrade | Yes |
| Online Upgrade | Yes |
| Dual-bin Backup | Yes |
| Factory Reset | Yes |
| Language | Chinese English |
| System Log | Yes |
| Diagnostics | Yes |
| Network Check | Yes |
| Physical | |
| LED Indicator | 1 × System LED indicator |
| Buttons | 1 × Reset button |
| Dimensions (W × D × H) | 298 mm x 298 mm x 65 mm (Without Mounting Bracket) |
| Weight | Main Unit: 3.5 kg Mounting Bracket: 1.35kg |
| DC Port Dimensions | Outer Diameter: 5.5 mm Inner Diameter: 2.1 mm Length: 10 mm |
| Installation | Wall-Mountable/Pole-Mountable |
| Mounting Bracket Dimensions (W × D × H) | 124 mm x 120 mm x 35 mm |
| Mounting Hole Pattern | 65 mm x 105 mm |
| Mounting Hole Diameter | 9 mm |
| Pole Diameter | 70 mm to 140 mm |
| Power Supplies | IEEE 802.3bt PoE DC 48V/1A |
| Power Consumption | ≤ 40W |
| PoE Power Budget | NA |
| Environmental | |
| Operating Temperature | -40℃ ~ 65℃ |
| Storage Temperature | -40℃ ~ 85℃ |
| Operating Humidity | 0% to 100% Noncondensing |
| Storage Humidity | 0% to 100% Noncondensing |
| IP (Ingress Protection) | IP68 |
| Port Surge | 4kV |
| MTBF | >400000H |
- Bảo hành: 5 năm.
